Docker Course #10: Final Project — Full-Stack App with Docker

1fullstack-docker-app/
2├── frontend/
3│   ├── public/
4│   ├── src/
5│   │   ├── App.jsx
6│   │   ├── index.js
7│   │   └── api.js
8│   ├── nginx.conf
9│   ├── Dockerfile
10│   └── package.json
11├── api/
12│   ├── src/
13│   │   ├── index.js
14│   │   ├── routes/
15│   │   │   └── tasks.js
16│   │   ├── middleware/
17│   │   │   └── cache.js
18│   │   └── db.js
19│   ├── Dockerfile
20│   └── package.json
21├── database/
22│   └── init.sql
23├── docker-compose.yml
24├── docker-compose.dev.yml
25├── docker-compose.prod.yml
26├── .env
27├── .env.example
28├── .dockerignore
29└── Makefile

1{
2  "name": "fullstack-api",
3  "version": "1.0.0",
4  "main": "src/index.js",
5  "scripts": {
6    "start": "node src/index.js",
7    "dev": "nodemon src/index.js",
8    "test": "jest --coverage"
9  },
10  "dependencies": {
11    "express": "^4.18.2",
12    "pg": "^8.12.0",
13    "redis": "^4.6.13",
14    "cors": "^2.8.5",
15    "helmet": "^7.1.0",
16    "morgan": "^1.10.0"
17  },
18  "devDependencies": {
19    "nodemon": "^3.1.0",
20    "jest": "^29.7.0"
21  }
22}

1const { Pool } = require('pg');
2
3const pool = new Pool({
4  host: process.env.DB_HOST || 'database',
5  port: parseInt(process.env.DB_PORT || '5432'),
6  database: process.env.DB_NAME || 'fullstack_app',
7  user: process.env.DB_USER || 'appuser',
8  password: process.env.DB_PASSWORD || 'apppass',
9  max: 20,
10  idleTimeoutMillis: 30000,
11  connectionTimeoutMillis: 5000,
12});
13
14pool.on('error', (err) => {
15  console.error('Unexpected database error:', err);
16});
17
18module.exports = pool;

1const { createClient } = require('redis');
2
3const redisClient = createClient({
4  url: process.env.REDIS_URL || 'redis://cache:6379',
5});
6
7redisClient.on('error', (err) => console.error('Redis error:', err));
8redisClient.on('connect', () => console.log('Connected to Redis'));
9
10// Connect to Redis
11(async () => {
12  await redisClient.connect();
13})();
14
15// Cache middleware factory
16function cacheMiddleware(keyPrefix, ttlSeconds = 60) {
17  return async (req, res, next) => {
18    const cacheKey = keyPrefix + ':' + req.originalUrl;
19
20    try {
21      const cached = await redisClient.get(cacheKey);
22      if (cached) {
23        console.log('Cache HIT:', cacheKey);
24        return res.json(JSON.parse(cached));
25      }
26      console.log('Cache MISS:', cacheKey);
27
28      // Override res.json to cache the response
29      const originalJson = res.json.bind(res);
30      res.json = (data) => {
31        redisClient.setEx(cacheKey, ttlSeconds, JSON.stringify(data));
32        return originalJson(data);
33      };
34
35      next();
36    } catch (err) {
37      console.error('Cache error:', err);
38      next(); // Continue without cache on error
39    }
40  };
41}
42
43// Invalidate cache by pattern
44async function invalidateCache(pattern) {
45  try {
46    const keys = await redisClient.keys(pattern);
47    if (keys.length > 0) {
48      await redisClient.del(keys);
49      console.log('Cache invalidated:', keys.length, 'keys');
50    }
51  } catch (err) {
52    console.error('Cache invalidation error:', err);
53  }
54}
55
56module.exports = { redisClient, cacheMiddleware, invalidateCache };

1const express = require('express');
2const pool = require('../db');
3const { cacheMiddleware, invalidateCache } = require('../middleware/cache');
4
5const router = express.Router();
6
7// GET /api/tasks - List all tasks (cached for 30 seconds)
8router.get('/', cacheMiddleware('tasks', 30), async (req, res) => {
9  try {
10    const result = await pool.query(
11      'SELECT * FROM tasks ORDER BY created_at DESC'
12    );
13    res.json({ data: result.rows, total: result.rowCount });
14  } catch (err) {
15    console.error('Error fetching tasks:', err);
16    res.status(500).json({ error: 'Failed to fetch tasks' });
17  }
18});
19
20// POST /api/tasks - Create a new task
21router.post('/', async (req, res) => {
22  const { title, description } = req.body;
23
24  if (!title || !title.trim()) {
25    return res.status(400).json({ error: 'Title is required' });
26  }
27
28  try {
29    const result = await pool.query(
30      'INSERT INTO tasks (title, description) VALUES ($1, $2) RETURNING *',
31      [title.trim(), (description || '').trim()]
32    );
33    await invalidateCache('tasks:*');
34    res.status(201).json({ data: result.rows[0] });
35  } catch (err) {
36    console.error('Error creating task:', err);
37    res.status(500).json({ error: 'Failed to create task' });
38  }
39});
40
41// PATCH /api/tasks/:id/complete - Mark a task as completed
42router.patch('/:id/complete', async (req, res) => {
43  try {
44    const result = await pool.query(
45      'UPDATE tasks SET completed = true, updated_at = NOW() WHERE id = $1 RETURNING *',
46      [req.params.id]
47    );
48    if (result.rowCount === 0) {
49      return res.status(404).json({ error: 'Task not found' });
50    }
51    await invalidateCache('tasks:*');
52    res.json({ data: result.rows[0] });
53  } catch (err) {
54    console.error('Error completing task:', err);
55    res.status(500).json({ error: 'Failed to complete task' });
56  }
57});
58
59// DELETE /api/tasks/:id - Delete a task
60router.delete('/:id', async (req, res) => {
61  try {
62    const result = await pool.query(
63      'DELETE FROM tasks WHERE id = $1 RETURNING *',
64      [req.params.id]
65    );
66    if (result.rowCount === 0) {
67      return res.status(404).json({ error: 'Task not found' });
68    }
69    await invalidateCache('tasks:*');
70    res.json({ message: 'Task deleted', data: result.rows[0] });
71  } catch (err) {
72    console.error('Error deleting task:', err);
73    res.status(500).json({ error: 'Failed to delete task' });
74  }
75});
76
77module.exports = router;

1const express = require('express');
2const cors = require('cors');
3const helmet = require('helmet');
4const morgan = require('morgan');
5const taskRoutes = require('./routes/tasks');
6
7const app = express();
8const PORT = process.env.PORT || 3000;
9
10// Middleware
11app.use(helmet());
12app.use(cors({ origin: process.env.CORS_ORIGIN || '*' }));
13app.use(morgan('combined'));
14app.use(express.json());
15
16// Routes
17app.use('/api/tasks', taskRoutes);
18
19// Health check endpoint
20app.get('/health', async (req, res) => {
21  const pool = require('./db');
22  try {
23    await pool.query('SELECT 1');
24    res.json({
25      status: 'healthy',
26      timestamp: new Date().toISOString(),
27      uptime: process.uptime(),
28      service: 'api',
29    });
30  } catch (err) {
31    res.status(503).json({ status: 'unhealthy', error: err.message });
32  }
33});
34
35// Start server
36app.listen(PORT, '0.0.0.0', () => {
37  console.log('API server running on port ' + PORT);
38  console.log('Environment: ' + (process.env.NODE_ENV || 'development'));
39});

1# api/Dockerfile
2
3# Stage 1: Install dependencies
4FROM node:20-alpine AS deps
5WORKDIR /app
6COPY package*.json ./
7RUN npm ci --only=production
8
9# Stage 2: Development
10FROM node:20-alpine AS development
11WORKDIR /app
12COPY package*.json ./
13RUN npm ci
14COPY . .
15EXPOSE 3000
16CMD ["npm", "run", "dev"]
17
18# Stage 3: Production
19FROM node:20-alpine AS production
20WORKDIR /app
21
22RUN addgroup -S appgroup && adduser -S appuser -G appgroup
23
24COPY --from=deps --chown=appuser:appgroup /app/node_modules ./node_modules
25COPY --chown=appuser:appgroup src ./src
26COPY --chown=appuser:appgroup package.json ./
27
28USER appuser
29EXPOSE 3000
30CMD ["node", "src/index.js"]

1# frontend/nginx.conf
2server {
3    listen 80;
4    server_name localhost;
5
6    # Serve static files
7    root /usr/share/nginx/html;
8    index index.html;
9
10    # SPA routing: send all non-file requests to index.html
11    location / {
12        try_files $uri $uri/ /index.html;
13    }
14
15    # Reverse proxy API requests to the backend
16    location /api/ {
17        proxy_pass http://api:3000;
18        proxy_http_version 1.1;
19        proxy_set_header Upgrade $http_upgrade;
20        proxy_set_header Connection 'upgrade';
21        proxy_set_header Host $host;
22        proxy_set_header X-Real-IP $remote_addr;
23        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
24        proxy_set_header X-Forwarded-Proto $scheme;
25        proxy_cache_bypass $http_upgrade;
26    }
27
28    # Health check endpoint
29    location /nginx-health {
30        access_log off;
31        return 200 "healthy";
32        add_header Content-Type text/plain;
33    }
34
35    # Security headers
36    add_header X-Frame-Options "SAMEORIGIN" always;
37    add_header X-Content-Type-Options "nosniff" always;
38    add_header X-XSS-Protection "1; mode=block" always;
39    add_header Referrer-Policy "strict-origin-when-cross-origin" always;
40
41    # Cache static assets
42    location ~* \.(js|css|png|jpg|jpeg|gif|ico|svg|woff|woff2)$ {
43        expires 1y;
44        add_header Cache-Control "public, immutable";
45    }
46
47    # Gzip compression
48    gzip on;
49    gzip_types text/plain text/css application/json application/javascript text/xml application/xml;
50    gzip_min_length 256;
51}

1# frontend/Dockerfile
2
3# Stage 1: Build React app
4FROM node:20-alpine AS builder
5WORKDIR /app
6
7COPY package*.json ./
8RUN npm ci
9
10COPY . .
11RUN npm run build
12
13# Stage 2: Serve with Nginx
14FROM nginx:alpine AS production
15
16# Remove default nginx config
17RUN rm /etc/nginx/conf.d/default.conf
18
19# Copy custom nginx config
20COPY nginx.conf /etc/nginx/conf.d/default.conf
21
22# Copy built React app
23COPY --from=builder /app/build /usr/share/nginx/html
24
25# Create non-root user for nginx
26RUN chown -R nginx:nginx /usr/share/nginx/html \
27    && chown -R nginx:nginx /var/cache/nginx \
28    && chown -R nginx:nginx /var/log/nginx \
29    && touch /var/run/nginx.pid \
30    && chown -R nginx:nginx /var/run/nginx.pid
31
32USER nginx
33EXPOSE 80
34CMD ["nginx", "-g", "daemon off;"]

1# database/init.sql
2-- Create the tasks table
3CREATE TABLE IF NOT EXISTS tasks (
4    id SERIAL PRIMARY KEY,
5    title VARCHAR(255) NOT NULL,
6    description TEXT DEFAULT '',
7    completed BOOLEAN DEFAULT FALSE,
8    created_at TIMESTAMP WITH TIME ZONE DEFAULT NOW(),
9    updated_at TIMESTAMP WITH TIME ZONE DEFAULT NOW()
10);
11
12-- Create an index for faster queries
13CREATE INDEX IF NOT EXISTS idx_tasks_completed ON tasks(completed);
14CREATE INDEX IF NOT EXISTS idx_tasks_created_at ON tasks(created_at DESC);
15
16-- Insert sample data
17INSERT INTO tasks (title, description) VALUES
18    ('Set up Docker environment', 'Install Docker Desktop and verify it works'),
19    ('Build the API', 'Create the Express.js REST API with PostgreSQL'),
20    ('Build the frontend', 'Create the React app with task management UI'),
21    ('Configure Docker Compose', 'Set up all services with health checks'),
22    ('Deploy to production', 'Push images and deploy the full stack');
23
24-- Display confirmation
25SELECT 'Database initialized with ' || COUNT(*) || ' sample tasks' AS status FROM tasks;

1# .env
2DB_HOST=database
3DB_PORT=5432
4DB_NAME=fullstack_app
5DB_USER=appuser
6DB_PASSWORD=secure_password_123
7REDIS_URL=redis://cache:6379
8NODE_ENV=production
9CORS_ORIGIN=http://localhost

1# docker-compose.yml - Base configuration
2
3services:
4  # ─── Frontend (React + Nginx) ───────────────────
5  frontend:
6    build:
7      context: ./frontend
8      target: production
9    restart: unless-stopped
10    ports:
11      - "80:80"
12    depends_on:
13      api:
14        condition: service_healthy
15    networks:
16      - frontend-net
17    healthcheck:
18      test: ["CMD", "wget", "--no-verbose", "--tries=1", "--spider", "http://localhost/nginx-health"]
19      interval: 30s
20      timeout: 5s
21      retries: 3
22      start_period: 10s
23
24  # ─── API (Node.js + Express) ────────────────────
25  api:
26    build:
27      context: ./api
28      target: production
29    restart: unless-stopped
30    environment:
31      NODE_ENV: ${NODE_ENV:-production}
32      DB_HOST: ${DB_HOST}
33      DB_PORT: ${DB_PORT}
34      DB_NAME: ${DB_NAME}
35      DB_USER: ${DB_USER}
36      DB_PASSWORD: ${DB_PASSWORD}
37      REDIS_URL: ${REDIS_URL}
38      CORS_ORIGIN: ${CORS_ORIGIN:-http://localhost}
39      PORT: 3000
40    depends_on:
41      database:
42        condition: service_healthy
43      cache:
44        condition: service_healthy
45    networks:
46      - frontend-net
47      - backend-net
48    healthcheck:
49      test: ["CMD", "wget", "--no-verbose", "--tries=1", "--spider", "http://localhost:3000/health"]
50      interval: 15s
51      timeout: 5s
52      retries: 5
53      start_period: 20s
54    cap_drop:
55      - ALL
56    security_opt:
57      - no-new-privileges:true
58
59  # ─── Database (PostgreSQL) ──────────────────────
60  database:
61    image: postgres:16-alpine
62    restart: unless-stopped
63    environment:
64      POSTGRES_DB: ${DB_NAME}
65      POSTGRES_USER: ${DB_USER}
66      POSTGRES_PASSWORD: ${DB_PASSWORD}
67    volumes:
68      - postgres-data:/var/lib/postgresql/data
69      - ./database/init.sql:/docker-entrypoint-initdb.d/01-init.sql:ro
70    networks:
71      - backend-net
72    healthcheck:
73      test: ["CMD-SHELL", "pg_isready -U ${DB_USER} -d ${DB_NAME}"]
74      interval: 10s
75      timeout: 5s
76      retries: 5
77      start_period: 30s
78    cap_drop:
79      - ALL
80    cap_add:
81      - CHOWN
82      - SETUID
83      - SETGID
84      - FOWNER
85      - DAC_READ_SEARCH
86
87  # ─── Cache (Redis) ─────────────────────────────
88  cache:
89    image: redis:7-alpine
90    restart: unless-stopped
91    command: redis-server --maxmemory 128mb --maxmemory-policy allkeys-lru --appendonly yes
92    volumes:
93      - redis-data:/data
94    networks:
95      - backend-net
96    healthcheck:
97      test: ["CMD", "redis-cli", "ping"]
98      interval: 10s
99      timeout: 5s
100      retries: 3
101      start_period: 10s
102    cap_drop:
103      - ALL
104
105volumes:
106  postgres-data:
107    name: fullstack-postgres-data
108  redis-data:
109    name: fullstack-redis-data
110
111networks:
112  frontend-net:
113    name: fullstack-frontend
114    driver: bridge
115  backend-net:
116    name: fullstack-backend
117    driver: bridge
118    internal: true

1# docker-compose.dev.yml - Development overrides
2
3services:
4  frontend:
5    build:
6      context: ./frontend
7      target: builder  # Use the build stage with source code
8    ports:
9      - "3001:3000"    # React dev server port
10    volumes:
11      - ./frontend/src:/app/src  # Hot reload
12    command: npm start
13    environment:
14      - REACT_APP_API_URL=http://localhost:3000
15
16  api:
17    build:
18      context: ./api
19      target: development  # Use development stage with nodemon
20    ports:
21      - "3000:3000"
22      - "9229:9229"    # Node.js debugger port
23    volumes:
24      - ./api/src:/app/src  # Hot reload
25    environment:
26      NODE_ENV: development
27
28  database:
29    ports:
30      - "5432:5432"    # Expose for local database tools
31
32  cache:
33    ports:
34      - "6379:6379"    # Expose for local Redis tools

1# docker-compose.prod.yml - Production overrides
2
3services:
4  frontend:
5    read_only: true
6    tmpfs:
7      - /tmp:rw,noexec,nosuid,size=16m
8      - /var/cache/nginx:rw,noexec,nosuid,size=64m
9      - /var/run:rw,noexec,nosuid,size=1m
10    deploy:
11      resources:
12        limits:
13          cpus: "0.5"
14          memory: 128M
15    logging:
16      driver: json-file
17      options:
18        max-size: "10m"
19        max-file: "3"
20
21  api:
22    read_only: true
23    tmpfs:
24      - /tmp:rw,noexec,nosuid,size=64m
25    deploy:
26      resources:
27        limits:
28          cpus: "1.0"
29          memory: 512M
30        reservations:
31          cpus: "0.25"
32          memory: 128M
33    logging:
34      driver: json-file
35      options:
36        max-size: "10m"
37        max-file: "5"
38
39  database:
40    read_only: true
41    tmpfs:
42      - /tmp:rw,noexec,nosuid,size=64m
43      - /run/postgresql:rw,noexec,nosuid,size=16m
44    deploy:
45      resources:
46        limits:
47          cpus: "1.0"
48          memory: 1G
49        reservations:
50          cpus: "0.5"
51          memory: 256M
52    logging:
53      driver: json-file
54      options:
55        max-size: "10m"
56        max-file: "5"
57
58  cache:
59    read_only: true
60    tmpfs:
61      - /tmp:rw,noexec,nosuid,size=16m
62    deploy:
63      resources:
64        limits:
65          cpus: "0.5"
66          memory: 256M
67    logging:
68      driver: json-file
69      options:
70        max-size: "5m"
71        max-file: "3"

1# Development (with hot reload, debug ports, exposed DB)
2docker compose -f docker-compose.yml -f docker-compose.dev.yml up -d
3
4# Production (with resource limits, read-only, security hardening)
5docker compose -f docker-compose.yml -f docker-compose.prod.yml up -d
6
7# View all running services
8docker compose ps
9
10# View logs for a specific service
11docker compose logs -f api
12
13# Run database migrations or seed data
14docker compose exec api node src/seed.js
15
16# Access the database directly (development only)
17docker compose exec database psql -U appuser -d fullstack_app
18
19# Access the Redis CLI
20docker compose exec cache redis-cli

1# Watch the startup sequence
2docker compose up -d && docker compose logs -f
3
4# Expected startup order:
5# [database]  PostgreSQL init process complete; ready for start up.
6# [cache]     Ready to accept connections
7# [api]       Connected to Redis
8# [api]       API server running on port 3000
9# [frontend]  nginx: the configuration file syntax is ok
10
11# Check health status of all services
12docker compose ps
13
14# Expected output:
15# NAME        SERVICE     STATUS                PORTS
16# frontend    frontend    running (healthy)     0.0.0.0:80->80/tcp
17# api         api         running (healthy)
18# database    database    running (healthy)
19# cache       cache       running (healthy)

1# .dockerignore
2node_modules
3npm-debug.log*
4.git
5.gitignore
6.env
7.env.*
8!.env.example
9docker-compose*.yml
10Dockerfile*
11README.md
12LICENSE
13.vscode
14.idea
15coverage
16.nyc_output
17*.md

1# Makefile
2.PHONY: dev prod down logs clean test
3
4# Start in development mode
5dev:
6	docker compose -f docker-compose.yml -f docker-compose.dev.yml up -d
7	@echo "Development environment started!"
8	@echo "Frontend: http://localhost:3001"
9	@echo "API:      http://localhost:3000"
10	@echo "Database: localhost:5432"
11
12# Start in production mode
13prod:
14	docker compose -f docker-compose.yml -f docker-compose.prod.yml up -d --build
15	@echo "Production environment started!"
16	@echo "App: http://localhost"
17
18# Stop all services
19down:
20	docker compose down
21
22# View logs
23logs:
24	docker compose logs -f
25
26# Clean everything (including volumes!)
27clean:
28	docker compose down -v --rmi local
29	@echo "All containers, volumes, and local images removed."
30
31# Run tests in containers
32test:
33	docker compose -f docker-compose.yml -f docker-compose.dev.yml run --rm api npm test
34
35# Database shell
36db-shell:
37	docker compose exec database psql -U appuser -d fullstack_app
38
39# Redis CLI
40redis-cli:
41	docker compose exec cache redis-cli

1# Usage:
2make dev      # Start development environment
3make prod     # Start production environment
4make down     # Stop everything
5make logs     # View logs
6make clean    # Remove everything including data
7make test     # Run tests
8make db-shell # Open PostgreSQL shell
