Docker Course #9: Docker in CI/CD — GitHub Actions and Automation
Welcome to the Docker Course - Part 9 of 10. In this article, you will learn how to integrate Docker into CI/CD pipelines using GitHub Actions to automate building, testing, and pushing your container images.
Source: Wikimedia Commons
In the previous articles, you learned how to build Docker images, use Docker Compose, optimize with multi-stage builds, and apply security best practices. Now it is time to automate everything so that every code change automatically builds, tests, and publishes your container images.
Prerequisites: You should be familiar with Git, GitHub, Docker images, multi-stage builds (Part 7), and Docker security (Part 8). A GitHub account is required to follow along.
Why Docker in CI/CD?
Continuous Integration and Continuous Delivery (CI/CD) is the practice of automatically building, testing, and deploying your application every time you push code changes. Docker fits naturally into CI/CD because:
- Consistency: The same image runs in CI, staging, and production
- Reproducibility: Builds produce identical images regardless of the CI runner
- Speed: Docker layer caching makes subsequent builds much faster
- Isolation: Tests run in containers without polluting the CI environment
- Immutability: Once an image is built and tagged, it never changes
A typical Docker CI/CD pipeline looks like this:
- Code push triggers the pipeline
- Build the Docker image using the Dockerfile
- Test by running tests inside the container
- Scan the image for vulnerabilities (Trivy)
- Push the image to a container registry (GHCR, Docker Hub, ECR)
- Deploy the new image to the target environment
GitHub Actions Basics for Docker
GitHub Actions is a CI/CD platform built into GitHub. Workflows are defined in YAML files inside the .github/workflows/ directory of your repository.
Here is the basic structure of a GitHub Actions workflow:
yaml
1# .github/workflows/docker-build.yml
2name: Docker Build and Push
3
4on:
5 push:
6 branches: [main]
7 pull_request:
8 branches: [main]
9
10env:
11 REGISTRY: ghcr.io
12 IMAGE_NAME: ${{ github.repository }}
13
14jobs:
15 build:
16 runs-on: ubuntu-latest
17
18 permissions:
19 contents: read
20 packages: write
21
22 steps:
23 - name: Checkout code
24 uses: actions/checkout@v4
25
26 - name: Set up Docker Buildx
27 uses: docker/setup-buildx-action@v3
28
29 - name: Log in to GitHub Container Registry
30 uses: docker/login-action@v3
31 with:
32 registry: ${{ env.REGISTRY }}
33 username: ${{ github.actor }}
34 password: ${{ secrets.GITHUB_TOKEN }}
35
36 - name: Build and push Docker image
37 uses: docker/build-push-action@v5
38 with:
39 context: .
40 push: ${{ github.event_name != 'pull_request' }}
41 tags: ${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}:latestKey components:
on- Triggers (push, pull_request, schedule, manual)env- Environment variables available to all jobsjobs- The work units that run on GitHub runnerspermissions- GITHUB_TOKEN permissions for the jobsteps- Individual actions within a job
Tip: The
GITHUB_TOKEN is automatically provided by GitHub Actions. You do not need to create it manually. It has permissions to push to GHCR for the current repository.
Building and Pushing to GHCR
GitHub Container Registry (GHCR) is a free container registry integrated with GitHub. Here is a complete workflow that builds, tags, and pushes images with proper metadata:
yaml
1# .github/workflows/docker-publish.yml
2name: Build and Publish Docker Image
3
4on:
5 push:
6 branches: [main]
7 tags: ['v*']
8 pull_request:
9 branches: [main]
10
11env:
12 REGISTRY: ghcr.io
13 IMAGE_NAME: ${{ github.repository }}
14
15jobs:
16 build-and-push:
17 runs-on: ubuntu-latest
18 permissions:
19 contents: read
20 packages: write
21 attestations: write
22 id-token: write
23
24 steps:
25 - name: Checkout repository
26 uses: actions/checkout@v4
27
28 - name: Set up Docker Buildx
29 uses: docker/setup-buildx-action@v3
30
31 - name: Log in to GHCR
32 if: github.event_name != 'pull_request'
33 uses: docker/login-action@v3
34 with:
35 registry: ${{ env.REGISTRY }}
36 username: ${{ github.actor }}
37 password: ${{ secrets.GITHUB_TOKEN }}
38
39 - name: Extract metadata (tags, labels)
40 id: meta
41 uses: docker/metadata-action@v5
42 with:
43 images: ${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}
44 tags: |
45 type=ref,event=branch
46 type=ref,event=pr
47 type=semver,pattern={{version}}
48 type=semver,pattern={{major}}.{{minor}}
49 type=sha,prefix=
50
51 - name: Build and push
52 id: push
53 uses: docker/build-push-action@v5
54 with:
55 context: .
56 push: ${{ github.event_name != 'pull_request' }}
57 tags: ${{ steps.meta.outputs.tags }}
58 labels: ${{ steps.meta.outputs.labels }}
59 cache-from: type=gha
60 cache-to: type=gha,mode=maxThis workflow produces smart tags based on the Git event:
| Git Event | Image Tag |
|---|---|
Push to main |
ghcr.io/user/repo:main |
| Pull request #42 | ghcr.io/user/repo:pr-42 |
Tag v1.2.3 |
ghcr.io/user/repo:1.2.3, :1.2 |
| Any commit | ghcr.io/user/repo:abc1234 (SHA) |
Caching with BuildKit in CI
Docker builds in CI can be slow because the runner starts fresh each time. BuildKit caching solves this by storing build layers between runs.
GitHub Actions Cache (GHA)
The simplest approach uses GitHub's built-in cache:
yaml
1- name: Build and push
2 uses: docker/build-push-action@v5
3 with:
4 context: .
5 push: true
6 tags: ${{ steps.meta.outputs.tags }}
7 cache-from: type=gha
8 cache-to: type=gha,mode=maxRegistry Cache
Store cache layers in the container registry itself:
yaml
1- name: Build and push
2 uses: docker/build-push-action@v5
3 with:
4 context: .
5 push: true
6 tags: ${{ steps.meta.outputs.tags }}
7 cache-from: type=registry,ref=${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}:buildcache
8 cache-to: type=registry,ref=${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}:buildcache,mode=maxInline Cache
Embed cache metadata directly in the image (simpler but less efficient):
yaml
1- name: Build and push
2 uses: docker/build-push-action@v5
3 with:
4 context: .
5 push: true
6 tags: ${{ steps.meta.outputs.tags }}
7 cache-from: type=registry,ref=${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}:latest
8 cache-to: type=inline
Which cache to use? For most projects,
type=gha is the best choice. It is fast, simple, and included with GitHub Actions. Use type=registry if you need to share cache across different CI systems or repositories.
Multi-Platform Builds
Modern applications often need to run on both AMD64 (Intel/AMD) and ARM64 (Apple Silicon, AWS Graviton, Raspberry Pi) architectures. Docker Buildx makes multi-platform builds easy:
yaml
1# .github/workflows/multi-platform.yml
2name: Multi-Platform Build
3
4on:
5 push:
6 tags: ['v*']
7
8jobs:
9 build:
10 runs-on: ubuntu-latest
11 permissions:
12 contents: read
13 packages: write
14
15 steps:
16 - name: Checkout
17 uses: actions/checkout@v4
18
19 - name: Set up QEMU (for cross-platform emulation)
20 uses: docker/setup-qemu-action@v3
21
22 - name: Set up Docker Buildx
23 uses: docker/setup-buildx-action@v3
24
25 - name: Log in to GHCR
26 uses: docker/login-action@v3
27 with:
28 registry: ghcr.io
29 username: ${{ github.actor }}
30 password: ${{ secrets.GITHUB_TOKEN }}
31
32 - name: Build and push multi-platform
33 uses: docker/build-push-action@v5
34 with:
35 context: .
36 platforms: linux/amd64,linux/arm64
37 push: true
38 tags: |
39 ghcr.io/${{ github.repository }}:latest
40 ghcr.io/${{ github.repository }}:${{ github.ref_name }}
41 cache-from: type=gha
42 cache-to: type=gha,mode=max
Performance note: Multi-platform builds with QEMU emulation can be slow (especially ARM64 on AMD64 runners). For faster builds, consider using native ARM64 runners (
runs-on: ubuntu-latest-arm64) or building each platform separately and creating a manifest list.
Automated Testing in Containers
Running tests inside Docker containers ensures your tests run in the same environment as production. Here are several approaches:
Approach 1: Test stage in Dockerfile
dockerfile
1# Dockerfile with test stage
2FROM node:20-alpine AS builder
3WORKDIR /app
4COPY package*.json ./
5RUN npm ci
6COPY . .
7
8# Test stage (can be targeted separately)
9FROM builder AS tester
10RUN npm run test
11RUN npm run lint
12
13# Production stage
14FROM node:20-alpine AS runtime
15WORKDIR /app
16COPY --from=builder /app/dist ./dist
17COPY --from=builder /app/node_modules ./node_modules
18CMD ["node", "dist/index.js"]yaml
1# Run tests in CI by targeting the test stage
2- name: Run tests
3 uses: docker/build-push-action@v5
4 with:
5 context: .
6 target: tester
7 push: false # Don't push the test imageApproach 2: Docker Compose for integration tests
yaml
1# docker-compose.test.yml
2services:
3 api:
4 build:
5 context: .
6 target: builder
7 command: npm run test:integration
8 environment:
9 DATABASE_URL: postgresql://test:test@database:5432/testdb
10 REDIS_URL: redis://cache:6379
11 depends_on:
12 database:
13 condition: service_healthy
14 cache:
15 condition: service_healthy
16
17 database:
18 image: postgres:16-alpine
19 environment:
20 POSTGRES_DB: testdb
21 POSTGRES_USER: test
22 POSTGRES_PASSWORD: test
23 healthcheck:
24 test: ["CMD-SHELL", "pg_isready -U test"]
25 interval: 5s
26 timeout: 5s
27 retries: 5
28
29 cache:
30 image: redis:7-alpine
31 healthcheck:
32 test: ["CMD", "redis-cli", "ping"]
33 interval: 5s
34 timeout: 5s
35 retries: 3yaml
1# GitHub Actions step for integration tests
2- name: Run integration tests
3 run: |
4 docker compose -f docker-compose.test.yml up --build --abort-on-container-exit --exit-code-from api
5
6- name: Clean up test environment
7 if: always()
8 run: docker compose -f docker-compose.test.yml down -vApproach 3: Service containers in GitHub Actions
yaml
1jobs:
2 test:
3 runs-on: ubuntu-latest
4
5 services:
6 postgres:
7 image: postgres:16-alpine
8 env:
9 POSTGRES_DB: testdb
10 POSTGRES_USER: test
11 POSTGRES_PASSWORD: test
12 ports:
13 - 5432:5432
14 options: >-
15 --health-cmd "pg_isready -U test"
16 --health-interval 10s
17 --health-timeout 5s
18 --health-retries 5
19
20 redis:
21 image: redis:7-alpine
22 ports:
23 - 6379:6379
24 options: >-
25 --health-cmd "redis-cli ping"
26 --health-interval 10s
27 --health-timeout 5s
28 --health-retries 5
29
30 steps:
31 - uses: actions/checkout@v4
32 - uses: actions/setup-node@v4
33 with:
34 node-version: 20
35 - run: npm ci
36 - run: npm run test:integration
37 env:
38 DATABASE_URL: postgresql://test:test@localhost:5432/testdb
39 REDIS_URL: redis://localhost:6379Complete Production Workflow
Here is a complete, production-ready GitHub Actions workflow that combines everything we have covered. This is the workflow you would use for a real project:
yaml
1# .github/workflows/ci-cd.yml
2name: CI/CD Pipeline
3
4on:
5 push:
6 branches: [main, develop]
7 tags: ['v*']
8 pull_request:
9 branches: [main]
10
11env:
12 REGISTRY: ghcr.io
13 IMAGE_NAME: ${{ github.repository }}
14
15jobs:
16 # Job 1: Run tests
17 test:
18 runs-on: ubuntu-latest
19 services:
20 postgres:
21 image: postgres:16-alpine
22 env:
23 POSTGRES_DB: testdb
24 POSTGRES_USER: test
25 POSTGRES_PASSWORD: testpass
26 ports:
27 - 5432:5432
28 options: >-
29 --health-cmd "pg_isready -U test"
30 --health-interval 10s
31 --health-timeout 5s
32 --health-retries 5
33
34 steps:
35 - uses: actions/checkout@v4
36 - uses: actions/setup-node@v4
37 with:
38 node-version: 20
39 cache: npm
40
41 - run: npm ci
42 - run: npm run lint
43 - run: npm run test
44 env:
45 DATABASE_URL: postgresql://test:testpass@localhost:5432/testdb
46
47 # Job 2: Build, scan, and push Docker image
48 build:
49 needs: test
50 runs-on: ubuntu-latest
51 permissions:
52 contents: read
53 packages: write
54 security-events: write
55
56 steps:
57 - name: Checkout
58 uses: actions/checkout@v4
59
60 - name: Set up Docker Buildx
61 uses: docker/setup-buildx-action@v3
62
63 - name: Log in to GHCR
64 if: github.event_name != 'pull_request'
65 uses: docker/login-action@v3
66 with:
67 registry: ${{ env.REGISTRY }}
68 username: ${{ github.actor }}
69 password: ${{ secrets.GITHUB_TOKEN }}
70
71 - name: Extract metadata
72 id: meta
73 uses: docker/metadata-action@v5
74 with:
75 images: ${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}
76 tags: |
77 type=ref,event=branch
78 type=ref,event=pr
79 type=semver,pattern={{version}}
80 type=semver,pattern={{major}}.{{minor}}
81 type=sha,prefix=
82
83 - name: Build image (for scanning)
84 uses: docker/build-push-action@v5
85 with:
86 context: .
87 load: true
88 tags: ${{ env.IMAGE_NAME }}:scan
89 cache-from: type=gha
90 cache-to: type=gha,mode=max
91
92 - name: Scan image with Trivy
93 uses: aquasecurity/trivy-action@master
94 with:
95 image-ref: ${{ env.IMAGE_NAME }}:scan
96 format: sarif
97 output: trivy-results.sarif
98 severity: CRITICAL,HIGH
99
100 - name: Upload Trivy scan results
101 uses: github/codeql-action/upload-sarif@v3
102 if: always()
103 with:
104 sarif_file: trivy-results.sarif
105
106 - name: Build and push
107 if: github.event_name != 'pull_request'
108 uses: docker/build-push-action@v5
109 with:
110 context: .
111 push: true
112 tags: ${{ steps.meta.outputs.tags }}
113 labels: ${{ steps.meta.outputs.labels }}
114 cache-from: type=gha
115 cache-to: type=gha,mode=max
116
117 # Job 3: Deploy (only on main branch or tags)
118 deploy:
119 needs: build
120 if: github.ref == 'refs/heads/main' || startsWith(github.ref, 'refs/tags/v')
121 runs-on: ubuntu-latest
122 environment: production
123
124 steps:
125 - name: Deploy to production
126 run: |
127 echo "Deploying ${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}:main"
128 # Add your deployment commands here:
129 # - SSH to server and docker pull + docker compose up
130 # - kubectl set image deployment/app ...
131 # - aws ecs update-service ...
132 echo "Deployment complete!"
Tip: Use GitHub Environments with protection rules (required reviewers, deployment branches) to control who can deploy to production. This adds a manual approval step before deploying.
Docker Layer Caching Strategies
Efficient caching can reduce your CI build times from minutes to seconds. Here is a summary of the caching strategies available:
| Strategy | Speed | Setup | Best For |
|---|---|---|---|
| GHA Cache | Fast | Simple | Most GitHub Actions workflows |
| Registry Cache | Medium | Simple | Cross-repo sharing, non-GitHub CI |
| Local Cache | Fastest | Complex | Self-hosted runners with persistent storage |
| Inline Cache | Slow | Simplest | Simple projects, quick setup |
Optimize your Dockerfile for caching by ordering instructions from least to most frequently changing:
dockerfile
1# GOOD: Optimized layer order for caching
2FROM node:20-alpine AS builder
3WORKDIR /app
4
5# 1. System dependencies (rarely change)
6RUN apk add --no-cache python3 make g++
7
8# 2. Package manifest (changes when dependencies change)
9COPY package*.json ./
10
11# 3. Install dependencies (cached unless package.json changes)
12RUN npm ci
13
14# 4. Source code (changes most frequently - last!)
15COPY . .
16RUN npm run buildFor more details, check the official Docker CI/CD documentation: https://docs.docker.com/build/ci/github-actions/
Summary and Next Steps
In this article, you learned how to automate Docker workflows with GitHub Actions. Here is what we covered:
- Docker in CI/CD: Why containers and automation are a natural fit
- GitHub Actions basics: Workflow structure, triggers, and permissions
- Building and pushing to GHCR: Smart tagging with metadata-action
- Caching strategies: GHA, registry, inline, and local caching
- Multi-platform builds: Building for AMD64 and ARM64
- Automated testing: Test stages, Docker Compose, and service containers
- Complete workflow: Test, build, scan, push, and deploy
- Layer caching: Dockerfile ordering for optimal cache hits
Next up: In Part 10 (the final article!), we will build a complete full-stack application with Docker: React frontend, Node.js API, PostgreSQL, and Redis. It is the final project that puts everything together. See you there!
Share:
CV
Comments
Sign in to leave a comment
No comments yet. Be the first!
